Lawn Tractor · 1971Unverified
Sears Hydro-Trac 14 917.25600
Sears Hydro-Trac 14 917.25600 — Garden tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
328 kg
Hover a source tag to verify
Overview
DistributorSearsReference
ManufacturerRoperReference
Garden tractorReference
Original price was $1,200 in 1971Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
14HP Briggs & Stratton 531cc 1-cyl gasolineReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement32.4 ciReference
Bore/Stroke90 x 83 mmReference
Power10.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionSundstrandReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
TypeSears 3- PointReference
Dimensions
Weight328 kgReference
Front tire16x6.50-8Reference
Rear tire23x9.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x9.50-12Reference
Length165 cmReference
Width93 cmReference
Height100 cmReference
Shipping weight328 kgReference
Sears Hydro-Trac 14 attachments
42" mid-mount mower deckReference
48" mid-mount mower deckReference
Hydro-Trac 14 Serial Number Location
Serial number plate on the rear of the HT14, below the seat.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
48" mid-mount mower deckReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
