Tractor · 1952Unverified
SFV 402
SFV 402 — Standard-tread tractor · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
2899 kg
Hover a source tag to verify
Overview
ManufacturerSFVReference
Standard-tread tractorReference
Built in Vierzon, FranceReference
Two-wheel driveReference
Open operator station.Reference
Engine
SFV 10.3L 1-cyl dieselReference
Fuel tank90.1 LReference
Drawbar (claimed)29.8 kWReference
Belt (claimed)33.6 kWReference
SFVReference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement10.3 LReference
Bore/Stroke225 x 260 mmReference
Rated RPM630Reference
Starter typeelectricReference
Coolant capacity65.0 LReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight2899 kgReference
Front tire6.50-20Reference
Rear tire12.75-28Reference
Ag front6.50-20Reference
Ag rear12.75-28Reference
Ag rear12-38Reference
Length337 cmReference
Width177 cmReference
Height180 cmReference
Ballasted weight3349 kgReference
Ground clearance35 cmReference
Capacities
Diameter54 cmReference
Width18 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
