Tractor · 1933Unverified

SFV H1

Name: SFV H1
Brand: SFV

SFV H1 — Standard-tread tractor · 22 hp. Reference specifications; pending source verification.

The SFV H1 is a compact tractor, rated at 22 hp, which places it among the smaller models in its class. It was produced from 1933 to 1940. The tractor features a 1-cylinder diesel liquid-cooled engine, which powers two-wheel drive via a 3-speed gearbox. The listed weight of the SFV H1 is 3000 kg, making it suitable for tasks on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

3000 kg

Catalogue coverage

Variants represented

Richest spec table

27 rows

Recorded power

22 hp

Recorded weight

3000 kg

Transmissions

3-speed gear

Production years

1933-1940

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSFVReference

Standard-tread tractorReference

Built in Vierzon, FranceReference

Two-wheel driveReference

Open operator station.Reference

Engine

SFV 10.3L 1-cyl dieselReference

Drawbar (claimed)16.4 kWReference

Belt (claimed)32.8 kWReference

SFVReference

dieselReference

1-cylinderReference

liquid-cooledReference

Displacement10.3 LReference

Bore/Stroke225 x 260 mmReference

Rated RPM630Reference

Coolant capacity63.0 LReference

Transmission

3-speed gearReference

TypegearReference

Gears3 forward and 1 reverseReference

Dimensions

Wheelbase192 cmReference

Weight3000 kgReference

Front tire6.50-20Reference

Rear tire12.75-28Reference

Ag front6.50-20Reference

Ag rear12.75-28Reference

Length329 cmReference

Width175 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
