Tractor · 1951Unverified
Sheppard Diesel SDO-3
Sheppard Diesel SDO-3 — Orchard/Vineyard tractor · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
2426 kg
Hover a source tag to verify
Overview
ManufacturerSheppard DieselReference
Orchard/Vineyard tractorReference
Built in Hanover, Pennsylvania, USAReference
Two-wheel driveReference
Final drivesspur gearReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Variants
SD-3row-cropReference
SDO-3orchardReference
SDG-3groveReference
Engine
Sheppard Diesel 3.1L 3-cyl dieselReference
Sheppard Diesel 3.5L 3-cyl dieselReference
Engine23.9 kWReference
Plows3Reference
Sheppard Diesel 6BReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.1 LReference
Bore/Stroke102 x 127 mmReference
Power23.9 kWReference
Fuel systemindirect injectionReference
Rated RPM1650Reference
Starter typeelectricReference
Sheppard Diesel 6EReference
Displacement3.5 LReference
Bore/Stroke108 x 127 mmReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Dimensions
Wheelbase234 cmReference
Weight2426 kgReference
Front tire6.00-16Reference
Rear tire13x26Reference
Ag front6.00-16Reference
Ag rear13x26Reference
Length345 cmReference
SDG-3 Height171 cmReference
SDO-3 Height177 cmReference
Front tread149 cmReference
Rear tread142 cmReference
Capacities
Diameter20 cmReference
Width19 cmReference
RPM1325Reference
Speed888.49 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
