Lawn Tractor · Unverified
Shibaura GT14
Shibaura GT14 — Lawn tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
350 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
10.4KW Shibaura 617cc 3-cyl dieselReference
Fuel tank11.0 LReference
Shibaura E643Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement37.65 ciReference
Power (gross)10.4 kWReference
Rated RPM3200Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Dimensions
Wheelbase119 cmReference
Weight350 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Weight86 kgReference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length179 cmReference
Height (steering wheel)114 cmReference
Shibaura GT14 attachments
121 cm mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH35Reference
48" Mower deck
Typemid-mount ShibauraReference
Type3-bladeReference
Cutting width121 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
