Lawn Tractor · 1992Unverified
Shibaura GT141
Shibaura GT141 — Garden tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
380 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station.Reference
Engine
10.4KW Shibaura 617cc 3-cyl dieselReference
Fuel tank15.9 LReference
Shibaura E643Reference
dieselReference
3-cylinderReference
liquid-cooled horizontal-shaftReference
Displacement37.7 ciReference
Bore/Stroke64 x 64 mmReference
Power10.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmechanicalReference
Dimensions
Wheelbase126 cmReference
Weight380 kgReference
Front tire16X6.50-8Reference
Rear tire23X10.50-12Reference
Lawn/turf front16X6.50-8Reference
Lawn/turf rear23X10.50-12Reference
Length191 cmReference
Width99 cmReference
Height (steering wheel)120 cmReference
Ground clearance16 cmReference
Front tread76 cmReference
Rear tread66/71 cmReference
Shibaura GT141 attachments
111 cm mid-mount mower deckReference
121 cm mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH28Reference
Attachment overview
111 cm mid-mount mower deckReference
121 cm mid-mount mower deckReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
