Tractor · Unverified
Shibaura SD1300
Shibaura SD1300 — Compact Utility tractor · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
1168 to 1290 pounds
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
SE13002WDReference
SE1300-04WDReference
Engine
Shibaura 0.7L 2-cyl dieselReference
Fuel tank12.1 LReference
Engine9.5 kWReference
Shibaura LEK752CReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement0.7 LReference
Bore/Stroke75 x 80 mmReference
Power9.5 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 3 reverseReference
Dimensions
Wheelbase121 cmReference
Weight1168 to 1290 poundsReference
Length209 cmReference
Width96 cmReference
Height (steering wheel)122 cmReference
Height (exhaust)176 cmReference
2WD Weight529 kgReference
4WD Weight585 kgReference
2WD Ground clearance26 cmReference
4WD Ground clearance24 cmReference
2WD Front tread73 cmReference
4WD Front tread72 cmReference
Rear tread72 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH45Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
