The Shibaura SD2240 is a 22 hp tractor, situated at the lower end of its weight class. It was manufactured from 1977 to 1978, equipped with a 2-cylinder diesel liquid-cooled engine and four-wheel drive. The tractor features a 12-speed gearbox and has an operating weight of 1158 kg. It is designed for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1158 kg
Catalogue coverage
Variants represented
2
Richest spec table
25 rows
Recorded power
22 hp
Recorded weight
1158 kg
Transmissions
12-speed
Production years
1977-1978
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Built in Matsumoto, JapanReference
Four-wheel driveReference
Open operator station.Reference
Variants
SD22002WD 12-speedReference
SD2200D2WD 24-speedReference
SD22404WD 12-speedReference
SD2240D4WD 24-speedReference
Engine
Shibaura 1.0L 2-cyl dieselReference
Engine16.4 kWReference
Shibaura LET852Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Power16.4 kWReference
Transmission
12-speedReference
24-speedReference
Gears12 forward and 4 reverseReference
Gears24 forward and 8 reverseReference
Dimensions
Weight1158 kgReference
Length256 cmReference
Width134 cmReference
Height142 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
