The Shibaura SD4003 is a compact tractor with a rated output of 40 hp, making it suitable for smaller-scale operations. It was manufactured from 1980 to 1985. The SD4003 is powered by a 4-cylinder diesel liquid-cooled engine, which is connected to a 12-speed gearbox and a two-wheel drive system. Its listed weight is 1641 kg, with an operational capacity of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1641 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
40 hp
Recorded weight
1641 kg
Transmissions
12-speed gear
Production years
1980-1985
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Built in Matsumoto, JapanReference
Two-wheel driveReference
Open operator station.Reference
Engine
Shibaura 2.1L 4-cyl dieselReference
Engine29.8 kWReference
Shibaura LEP854AReference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement2.1 LReference
Bore/Stroke85 x 94 mmReference
Power29.8 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
24-speed creeperReference
TypegearReference
Gears12 forward and 4 reverseReference
TypecreeperReference
Gears24 forward and 8 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight1641 kgReference
Front tire6.00-16Reference
Rear tire12.4/11-28Reference
Standard tires (ag)Front: 6.00-16. Rear: 12.4/11-28Reference
Length337 cmReference
Width152 cmReference
Height193 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
