Tractor · 1977Unverified

Shibaura SD4340

Name: Shibaura SD4340
Brand: Shibaura

Shibaura SD4340 — SD0 Series · 36 hp. Reference specifications; pending source verification.

The Shibaura SD4340 is a compact tractor model rated at 36 hp, making it a suitable choice for smaller-scale operations. It features a 4-cylinder diesel liquid-cooled engine and a 24-speed gearbox, driving through four-wheel drive. Manufactured from 1977 to 1980, the SD4340 has a listed weight of 1632 kg and is designed to handle tasks on land areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

36 hp

Weight

1632 kg

Catalogue coverage

Variants represented

Richest spec table

67 rows

Recorded power

36 hp

Recorded weight

1632 kg

Transmissions

24-speed gear

Production years

1977-1980

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerShibauraReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

SteeringpowerReference

Mechanical drum brakesReference

Open operator station. Available two-post ROPS and canopy.Reference

Variants

SD43002WDReference

SD43404WDReference

Engine

Shibaura 2.1L 4-cyl dieselReference

Engine32.1 kWReference

Shibaura LEP854AReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.1 LReference

Bore/Stroke85 x 94 mmReference

Power32.1 kWReference

Compression22:1Reference

Rated RPM2500Reference

Torque121.0 NmReference

Torque RPM2000Reference

StarterelectricReference

Starter volts12Reference

Starter power2.1 kWReference

Transmission

24-speed gearReference

TypegearReference

Gears24 forward and 8 reverseReference

Clutchdry discReference

Oil capacity35.0 LReference

Three gears, plus reverse, in four ranges. Tractor must be stopped, and clutch used, to shift gears and range. Additional creeper range doubles the number of available speeds.Reference

PTO & Hydraulics

PTO (claimed)26.8 kWReference

Hydraulic system34.8 LReference

Typeopen centerReference

Capacity34.8 LReference

Pressure147.1 barReference

Valves1 or 2Reference

Pump flow26.9 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift (at ends)1969 kgReference

Rear PTOtransmissionReference

Rear PTO Type540 (1.375)Reference

Engine RPM546@2500Reference

Engine RPM701@2500Reference

Engine RPM1042@2500Reference

Engine RPM1320@2500Reference

Capacities

Fuel34.8 LReference

Dimensions

Wheelbase187 cmReference

Weight1632 kgReference

Front tire8.00x18Reference

Rear tire12.4/11-28Reference

Ag front8.00x18Reference

Ag rear12.4/11-28Reference

Ag rear14.9x24Reference

Length337 cmReference

Width151 cmReference

Height (steering wheel)151 cmReference

Ground clearance38 cmReference

Front tread119 cmReference

Rear tread119 to 150 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps20Reference

Battery volts12Reference

Battery AH100Reference

Speeds

With 12.4/11-28 rear tires. Creeper speeds are 13% of standard speeds.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
