Shibaura SE1300
Shibaura SE1300 — Compact Utility tractor · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Weight
508 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Two-wheel driveReference
Open operator station.Reference
Variants
SE13002WDReference
SE13404WDReference
Engine
Shibaura 0.7L 2-cyl dieselReference
Fuel tank14.0 LReference
Engine9.7 kWReference
Shibaura LEK 752CReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement0.7 LReference
Bore/Stroke75 x 80 mmReference
Power9.7 kWReference
Compression23.1:1Reference
Rated RPM2600Reference
Torque39.3 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Transmission
10-speed gearReference
TypegearReference
Gears10 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)8.2 kWReference
Type5.3Reference
Pump flow10.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)580 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM539@2500Reference
Engine RPM805@2500Reference
Engine RPM1258@2500Reference
Dimensions
Weight508 kgReference
Front tire4.00x12Reference
Rear tire7.00x16Reference
Ag front4.00x12Reference
Ag rear7.00x16Reference
Length241 cmReference
Width106 cmReference
Height (steering wheel)124 cmReference
Max weight1305 kgReference
Front tread76 to 103 cmReference
Rear tread89 to 116 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
