Shibaura SE3040
Shibaura SE3040 — SE SeriesCompact Utility tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
1164 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Four-wheel driveReference
Mechanical shoe brakesReference
Two-post ROPS.Reference
Variants
SE30002WDReference
SE30404WDReference
Engine
Shibaura 1.4L 3-cyl dieselReference
Fuel tank29.1 LReference
Engine22.4 kWReference
Shibaura LEM853Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke85 x 84 mmReference
Power22.4 kWReference
Compression21.1:1Reference
Rated RPM2800Reference
Operating RPM1400-2800Reference
Torque82.0 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
TypegearReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)19.8 kWReference
Typeopen centerReference
Pressure147.1 barReference
Valves1Reference
Pump flow22.3 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1099 kgReference
Rear PTOliveReference
Clutchtwo-stageReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight1164 kgReference
Front tire6.00x16Reference
Rear tire12.4x24Reference
Ag front6.00x16Reference
Ag rear12.4x24Reference
Length302 cmReference
Width157 cmReference
Height (steering wheel)151 cmReference
Max weight2848 kgReference
Ground clearance35 cmReference
Front tread113 cmReference
Rear tread116 to 154 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
