Tractor · 1983Unverified
Shibaura SE5340
Shibaura SE5340 — SE Series · 52 hp. Reference specifications; pending source verification.
The Shibaura SE5340 is a compact tractor with a rating of 52 hp, making it one of the smaller options in its class. Manufactured between 1983 and 1987, it features a 3-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system with a 16-speed gearbox. The tractor's listed weight is 2520 kg, and it is designed for use on areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
2520 kg
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
52 hp
Recorded weight
2520 kg
Transmissions
16-speed synchromesh
Production years
1983-1987
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Open operator station.Reference
Engine
Shibaura 3.1L 3-cyl dieselReference
Fuel tank60.2 LReference
Engine39.0 kWReference
Shibaura LER1053Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.1 LReference
Power39.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchromeshReference
TypesynchromeshReference
Gears16 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeII/IReference
Controlposition and draft controlReference
Rear PTO Type540/800/1000Reference
Dimensions
Wheelbase210 cmReference
Weight2520 kgReference
Front tire8.3-24Reference
Rear tire14.9-28Reference
Ag front8.3-24Reference
Ag rear14.9-28Reference
Length370 cmReference
Width172 cmReference
Height243 cmReference
Ground clearance34 cmReference
Front tread133 cmReference
Rear tread134 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH150Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
