Tractor · Unverified
Shibaura SE7300T
Shibaura SE7300T — SE SeriesUtility tractor · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Weight
2596 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Utility tractorReference
Built in Matsumoto, JapanReference
Two-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
SE7300T2WDReference
SE7340T4WDReference
Engine
Shibaura 3.4L 3-cyl dieselReference
Fuel tank60.0 LReference
Engine54.4 kWReference
Shibaura LER1103TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke110 x 120 mmReference
Power54.4 kWReference
Compression17:1Reference
Rated RPM2200Reference
Torque284.5 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Starter power3.0 kWReference
Transmission
16-speed synchromeshReference
TypesynchromeshReference
Gears16 forward and 4 reverseReference
Clutch305mm dry discReference
PTO & Hydraulics
Rear TypeII/IReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM622@2200Reference
Engine RPM800@2200Reference
Engine RPM1100@2200Reference
Dimensions
Weight2596 kgReference
Length370 cmReference
Width187 cmReference
Height248 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
