Tractor · Unverified
Shibaura SE8340
Shibaura SE8340 — SE SeriesUtility tractor · 72 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
72 hp
Weight
3538 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Utility tractorReference
Built in Matsumoto, JapanReference
Four-wheel driveReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
SE83002WDReference
SE83404WDReference
Engine
Shibaura 4.6L 4-cyl dieselReference
Engine61.9 kWReference
Shibaura LEA1104Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke110 x 120 mmReference
Power61.9 kWReference
Compression17.1:1Reference
Rated RPM2200Reference
Operating RPM1500-2200Reference
Torque275.0 NmReference
Torque RPM1500Reference
Starter typeelectricReference
Transmission
16-speed constant meshReference
Typeconstant meshReference
Gears16 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)53.7 kWReference
Hydraulic system25.0 LReference
Typeopen centerReference
Capacity25.0 LReference
Valves1 to 3Reference
Pump flow35.2 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)2500 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2200Reference
Engine RPM800@2200Reference
Engine RPM1000@2200Reference
Capacities
Fuel99.9 LReference
Dimensions
Weight3538 kgReference
Front tire11.2x24Reference
Rear tire18.4x30Reference
Ag front11.2x24Reference
Ag rear18.4x30Reference
Length390 cmReference
Width188 cmReference
Height271 cmReference
Height (steering wheel)179 cmReference
Max weight7257 kgReference
Ground clearance39 cmReference
Front tread144 to 182 cmReference
Rear tread144 to 194 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
