Tractor · Unverified

Shibaura SE8340

Name: Shibaura SE8340
Brand: Shibaura

Shibaura SE8340 — SE SeriesUtility tractor · 72 hp. Reference specifications; pending source verification.

The Shibaura SE8340 is a tractor with a rated output of 72 hp, placing it in the middle of its class for power. It features a 4-cylinder diesel liquid-cooled engine, which powers four-wheel drive through a 16-speed gearbox. The listed weight of the Shibaura SE8340 is 3538 kg, and it is suited for jobs covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

72 hp

Weight

3538 kg

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

72 hp

Recorded weight

3538 kg

Transmissions

16-speed constant mesh

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerShibauraReference

Utility tractorReference

Built in Matsumoto, JapanReference

Four-wheel driveReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Variants

SE83002WDReference

SE83404WDReference

Engine

Shibaura 4.6L 4-cyl dieselReference

Engine61.9 kWReference

Shibaura LEA1104Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.6 LReference

Bore/Stroke110 x 120 mmReference

Power61.9 kWReference

Compression17.1:1Reference

Rated RPM2200Reference

Operating RPM1500-2200Reference

Torque275.0 NmReference

Torque RPM1500Reference

Starter typeelectricReference

Transmission

16-speed constant meshReference

Typeconstant meshReference

Gears16 forward and 4 reverseReference

Clutchdry discReference

PTO & Hydraulics

PTO (claimed)53.7 kWReference

Hydraulic system25.0 LReference

Typeopen centerReference

Capacity25.0 LReference

Valves1 to 3Reference

Pump flow35.2 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift (at ends)2500 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2200Reference

Engine RPM800@2200Reference

Engine RPM1000@2200Reference

Capacities

Fuel99.9 LReference

Dimensions

Weight3538 kgReference

Front tire11.2x24Reference

Rear tire18.4x30Reference

Ag front11.2x24Reference

Ag rear18.4x30Reference

Length390 cmReference

Width188 cmReference

Height271 cmReference

Height (steering wheel)179 cmReference

Max weight7257 kgReference

Ground clearance39 cmReference

Front tread144 to 182 cmReference

Rear tread144 to 194 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
