Shibaura SP2100
Shibaura SP2100 — SP SeriesCompact Utility tractor · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
539 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Variants
SP21002WDReference
SP21404WDReference
Engine
Shibaura 1.0L 3-cyl dieselReference
Fuel tank18.2 LReference
Engine15.4 kWReference
Shibaura S753Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke75 x 72 mmReference
Power15.4 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed synchromeshReference
TypesynchromeshReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeJIS1Reference
Controlposition controlReference
Rear PTO Type540 (1.375)Reference
Engine RPM535@2600Reference
Engine RPM806@2600Reference
Engine RPM1053@2600Reference
Dimensions
Wheelbase133 cmReference
Weight539 kgReference
Front tire4.00-12Reference
Rear tire9.5-20Reference
Standard tires (ag)Front: 4.00-12. Rear: 9.5-20Reference
Length250 cmReference
Width104 cmReference
Height178 cmReference
Ground clearance34 cmReference
Front tread73 cmReference
Rear tread81 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH65Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
