Tractor · Unverified
Shibaura SP2500
Shibaura SP2500 — SP SeriesCompact Utility tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
859 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Variants
SP25002WDReference
SP25404WDReference
Engine
Shibaura 1.3L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine18.4 kWReference
Shibaura J843Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke84 x 80 mmReference
Power18.4 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchromeshReference
TypesynchromeshReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1349 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM559@2600Reference
Engine RPM778@2600Reference
Engine RPM1242@2600Reference
Dimensions
Wheelbase148 cmReference
Weight859 kgReference
Front tire4.00-15Reference
Rear tire9.5-24Reference
Standard tires (ag)Front: 4.00-15. Rear: 9.5-24Reference
Length254 cmReference
Width118 cmReference
Height182 cmReference
Ground clearance32 cmReference
Front tread93 cmReference
Rear tread94 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH70Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
