Tractor · Unverified
Shibaura SP5000
Shibaura SP5000 — SP SeriesCompact Utility tractor · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
1779 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Two-wheel driveReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Variants
SP50002WDReference
SP50404WDReference
Engine
Shibaura 2.3L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine (gross)36.8 kWReference
Shibaura T845BReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke85 x 100 mmReference
Power (gross)36.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed partially synchronizedReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow36.0 lpmReference
Rear TypeIReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift2075 kgReference
Rear PTOliveReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase196 cmReference
Weight1779 kgReference
Front tire6.50-16Reference
Rear tire12.4-32Reference
Standard tires (ag)Front: 6.50-16. Rear: 12.4-32Reference
Length356 cmReference
Width167 cmReference
Height229 cmReference
Ground clearance43 cmReference
Front tread123 to 184 cmReference
Rear tread123 to 194 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH100Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
