Tractor · Unverified
Shibaura SX21
Shibaura SX21 — Compact Utility tractor · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
694 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Compact Utility tractorReference
Built in Matsumoto, JapanReference
Four-wheel driveReference
SteeringpowerReference
Wet disc brakesReference
Engine
Shibaura 1.0L 3-cyl dieselReference
Fuel tank29.5 LReference
Engine15.7 kWReference
Shibaura S753Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke75 x 72 mmReference
Power15.7 kWReference
Compression24:1Reference
Rated RPM3000Reference
Idle RPM1300-3200Reference
Firing order1-2-3Reference
Starter volts12Reference
Starter power1.2 kWReference
Oil capacity3.3 LReference
Coolant capacity3.5 LReference
Intake valve clearance0.203 mmReference
Exhaust valve clearance0.203 mmReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity13.0 LReference
PTO & Hydraulics
PTO (claimed)11.9 kWReference
Typeopen centerReference
Pressure130.0 barReference
Valves1Reference
Pump flow14.2 lpmReference
Steering flow7.0 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)317 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2992Reference
Mid PTOstandardReference
Mid PTO Type2200Reference
Engine RPM2200@3020Reference
Dimensions
Wheelbase139 cmReference
Weight694 kgReference
Front tire4.00-9Reference
Rear tire7-14Reference
Ag front4.00-9Reference
Ag rear7-14Reference
Lawn/turf front18x8.50-8Reference
Lawn/turf rear26x12.00-12Reference
Length248 cmReference
Width109 cmReference
Ground clearance23 cmReference
Front tread90 cmReference
Rear tread90 cmReference
Steering wheel127 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery volts12Reference
Shibaura SX21 Height
Hood113 cmReference
ROPS228 cmReference
Speeds
With 26x12.00-12 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
