Tractor · Unverified
Shibaura V450F
Shibaura V450F — Utility tractor · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2100 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS.Reference
Engine
Shibaura 2.7L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine37.3 kWReference
Shibaura S4F7Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Power37.3 kWReference
Compression17:1Reference
Rated RPM2500Reference
Starter typeelectricReference
Oil capacity8.5 LReference
Transmission
24-speed synchromeshReference
TypesynchromeshReference
Gears24 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM585@2500Reference
Engine RPM722@2500Reference
Engine RPM1142@2500Reference
Engine RPM1363@2500Reference
Dimensions
Wheelbase196 cmReference
Weight2100 kgReference
Front tire9.5-20Reference
Rear tire12.4-32Reference
Standard tires (ag)Front: 9.5-20. Rear: 12.4-32Reference
Length356 cmReference
Width167 cmReference
Height (exhaust)245 cmReference
Ground clearance36 cmReference
Front tread121 to 166 cmReference
Rear tread123 to 194 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
