Shibaura V490F
Shibaura V490F — V SeriesUtility tractor · 89 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
89 hp
Weight
2945 kg
Hover a source tag to verify
Overview
ManufacturerShibauraReference
Utility tractorReference
Drive4x4 MFWD 4WDReference
Drive4x4 HFWD 4WDReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Engine
Perkins 4.0L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine66.2 kWReference
PerkinsReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power66.2 kWReference
Fuel system1004.4TReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.8 LReference
Transmission
32-speed partially synchronizedReference
Typepartially synchronizedReference
Gears32 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeJISII/IReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM645@2200Reference
Engine RPM872@2200Reference
Engine RPM1167@2200Reference
Dimensions
Wheelbase225 cmReference
Weight2945 kgReference
Front tire9.5-24Reference
Rear tire16.9-30Reference
Standard tires (ag)Front: 9.5-24. Rear: 16.9-30Reference
Length363 cmReference
Width188 cmReference
Height255 cmReference
Ground clearance41 cmReference
Front tread135 to 175 cmReference
Rear tread123 to 195 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH140Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
