Tractor · 1937Unverified
Silver King 4-Wheel
Silver King 4-Wheel — Standard-tread tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
952 kg
Hover a source tag to verify
Overview
ManufacturerSilver King (a part of Fate-Root-Heath)Reference
Standard-tread tractorReference
Built in Plymouth, Ohio, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Dimensions
3-Wheelrow-crop three-wheelReference
4-Wheelstandard four-wheelReference
Wheelbase152 cmReference
Weight952 kgReference
Front tire5.50-16Reference
Rear tire9.00-24Reference
Ag front5.50-16Reference
Ag rear9.00-24Reference
Ag front24-inch steelReference
Ag rear42-inch steelReference
Length246 cmReference
Width121 cmReference
Height124 cmReference
Rear tread96 cmReference
Rear tread111 cmReference
Engine
Hercules 2.2L 4-cyl gasolineReference
Fuel tank36.0 LReference
Engine18.6 kWReference
Plows1 (14-inch)Reference
Hercules IXBReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke83 x 102 mmReference
Power18.6 kWReference
Air cleaneroil bathReference
Rated RPM1400Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutchdry discReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
