Lawn Tractor · 1976Unverified
Simplicity Baron 7013
Simplicity Baron 7013 — Garden tractor · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
369 kg
Hover a source tag to verify
Overview
ManufacturerSimplicityReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
13HP Briggs & Stratton 494cc 1-cyl gasolineReference
Fuel tank11.4 LReference
Briggs & Stratton 302431Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement30.16 ciReference
Bore/Stroke87 x 83 mmReference
Power (gross)9.7 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
4-speed gearReference
Typebelt-driven gearReference
Gears4 forward and reverseReference
Oil capacity2.0 LReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmechanicalReference
Dimensions
Wheelbase122 cmReference
Weight369 kgReference
Front tire16-6.50x8Reference
Rear tire23-8.50x12Reference
Lawn/turf front16-6.50x8Reference
Lawn/turf rear23-8.50x12Reference
Length170 cmReference
Width95 cmReference
Height (steering wheel)100 cmReference
Height (hood)90 cmReference
Ground clearance20 cmReference
Front tread76 cmReference
Rear tread68 cmReference
Simplicity 7013 attachments
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
