Lawn Tractor · 2008Unverified
Simplicity Coronet 13.5/30
Simplicity Coronet 13.5/30 — Coronet Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
188 kg
Hover a source tag to verify
Overview
ManufacturerSimplicity (a part of Briggs & Stratton)Reference
Riding lawn mowerReference
Original price$2,270 (2008 )Reference
Original price$2,450 (2010 )Reference
Original price$2,399 (2012 )Reference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station with 13-inch seat.Reference
Variants
RE200similar Snapper modelReference
Engine
13.5HP Briggs & Stratton 344cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton IntekReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement21 ciReference
Bore/Stroke87 x 57 mmReference
Power (gross)10.1 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro Gear 510Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase109 cmReference
Weight188 kgReference
Front tire13x5.0-6Reference
Rear tire16x6.5-8Reference
Lawn/turf front13x5.0-6Reference
Lawn/turf rear16x6.5-8Reference
Length154 cmReference
Width83 cmReference
Height104 cmReference
Front axleSteelReference
Rear axle19 mmReference
Simplicity Coronet 13.5/30 attachments
30" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA230Reference
Battery volts12Reference
30" Mower deck
Typemid-mount SimplicityReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Overall width91 cmReference
Cut height2 to 9 cmReference
Cut positionsinfiniteReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
