Lawn Tractor · 1999Unverified
Simplicity Express 15.5H
Simplicity Express 15.5H — Express Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
206 kg
Hover a source tag to verify
Overview
ManufacturerSimplicityReference
Lawn tractorReference
Original price was $1,999 in 2000Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
15.5HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton IntekReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)11.6 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq K51Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity2.4 LReference
Oil typeSAE 10W-30 SG/CDReference
Oil change250 hReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Weight206 kgReference
Front tire15x6.0-6Reference
Rear tire18x8.5-8Reference
Weight36 kgReference
Lawn/turf front15x6.0-6Reference
Lawn/turf rear18x8.5-8Reference
Length172 cmReference
Width91 cmReference
Height (steering wheel)104 cmReference
Height (hood)86 cmReference
Simplicity Express 15.5H attachments
38" mid-mount mower deckReference
bladeReference
Express 15.5H Serial Number Location
Left-front of tractor frame, near front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
BladeReference
38" Mower deck
Typemid-mount Simplicity 1693464Reference
Type2-blade with manual liftReference
Cutting width96 cmReference
Overall width125 cmReference
Cut height3 to 9 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
