Lawn Tractor · 1999Unverified
Simplicity Express 17H
Simplicity Express 17H — Express Series · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
206 kg
Hover a source tag to verify
Overview
ManufacturerSimplicityReference
Lawn tractorReference
Original price was $2,499 in 2000Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
17HP Briggs & Stratton 501cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton IntekReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement30.6 ciReference
Bore/Stroke91 x 78 mmReference
Power (gross)12.7 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.7 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq K51Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity2.4 LReference
Oil typeSAE 10W-30 SG/CDReference
Oil change250 hReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Weight206 kgReference
Front tire15x6.0-6Reference
Rear tire20x8.0-8Reference
Weight48 kgReference
Lawn/turf front15x6.0-6Reference
Lawn/turf rear20x8.0-8Reference
Length172 cmReference
Width91 cmReference
Height (steering wheel)104 cmReference
Height (hood)86 cmReference
Simplicity Express 17H attachments
44" mid-mount mower deckReference
bladeReference
Express 17H Serial Numbers
Location:Left-front of tractor frame, near front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
BladeReference
44" Mower deck
Typemid-mount SimplicityReference
Type3-blade with manual liftReference
Cutting width111 cmReference
Overall width142 cmReference
Cut height3 to 9 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
