Search/Lawn Tractor/Simplicity/Landlord 9HP

cab interior

Lawn Tractor · 1964Unverified

Simplicity Landlord 9HP

Name: Simplicity Landlord 9HP
Brand: Simplicity

Simplicity Landlord 9HP — Landlord Series · 9 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

9 hp

Weight

308 kg

Hover a source tag to verify

Overview

ManufacturerSimplicity (a part of Allis Chalmers)Reference

Garden tractorReference

Built in Port Washington, Wisconsin, USAReference

Two-wheel driveReference

Manual steeringReference

Mechanical band brakesReference

Open operator station.Reference

Variants

990308manual startReference

990314electric startReference

990350mechanical liftReference

990351hydraulic liftReference

Engine

9HP Briggs & Stratton 392cc 1-cyl gasolineReference

Briggs & Stratton 243431Reference

gasolineReference

1-cylinderReference

air-cooled horizontal-shaftReference

Displacement23.94 ciReference

Bore/Stroke78 x 83 mmReference

Power (gross)6.7 kWReference

Startermanual recoilReference

StarterelectricReference

Starter volts12Reference

Oil change25 hReference

Transmission

3-speed gearReference

6-speed gearReference

Typeshaft-driven gearReference

Gears3 forward and 1 reverseReference

Oil capacity1.4 LReference

Oil typeSAE 90Reference

TypegearReference

Gears6 forward and 2 reverseReference

The optional High-Low range speed kit provides a lower range for each gear.Reference

PTO & Hydraulics

Mid PTOindependentReference

Clutchmechanical idler pulleyReference

Dimensions

Wheelbase113 cmReference

Weight308 kgReference

Front tire4.80x8Reference

Rear tire8-12Reference

Lawn/turf front4.80x8Reference

Lawn/turf rear8-12Reference

Length160 cmReference

Width86 cmReference

Height (steering wheel)93 cmReference

Height (hood)83 cmReference

Shipping weight308 kgReference
