Lawn Tractor · 1968Unverified
Simplicity Serf 515
Simplicity Serf 515 — Serf Series · 5 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
5 hp
Weight
116 kg
Hover a source tag to verify
Overview
ManufacturerSimplicity (a part of Allis Chalmers)Reference
Lawn tractorReference
Original price was $313 in 1968Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
5HP Briggs & Stratton 206cc 1-cyl gasolineReference
Briggs & Stratton 130000Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement12.57 ciReference
Bore/Stroke65 x 62 mmReference
Power3.7 kWReference
Fuel systemcarburetorReference
Starter typemanual recoilReference
Oil capacity0.9 LReference
Transmission
2-speed gearReference
Typebelt-driven gearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight116 kgReference
Front tire4.00x6Reference
Rear tire4.80/4.00x8Reference
Weight29 kgReference
Lawn/turf front4.00x6Reference
Lawn/turf rear4.80/4.00x8Reference
Length130 cmReference
Width66 cmReference
Shipping weight116 kgReference
Simplicity Serf 515 attachments
28" mid-mount mower deckReference
bladeReference
Attachment overview
28" mid-mount mower deckReference
BladeReference
28" Mower deck
Typemid-mount Simplicity 990442Reference
Type2-blade with manual liftReference
Cutting width71 cmReference
Cut height3 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
