Lawn Tractor · 1971Unverified
Simplicity Sovereign 3314H 990655
Simplicity Sovereign 3314H 990655 — Sovereign Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
344 kg
Hover a source tag to verify
Overview
ManufacturerSimplicityReference
Garden tractorReference
Manual steeringReference
Open operator station.Reference
Variants
3314VgearReference
3314HhydrostaticReference
Engine
14HP Briggs & Stratton 531cc 1-cyl gasolineReference
Briggs & Stratton 320421Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement32.4 ciReference
Bore/Stroke90 x 83 mmReference
Power10.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
Clutchmechanial idler pulleyReference
Dimensions
Wheelbase121 cmReference
Weight344 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length170 cmReference
Width91 cmReference
Height99 cmReference
Simplicity 3314H attachments
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
