Tractor · 1972Unverified
Skoda-LIAZ ST180
Skoda-LIAZ ST180 — Four-wheel Drive (4WD) tractor · 180 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
180 hp
Weight
7484 kg
Hover a source tag to verify
Overview
ManufacturerSkoda-LIAZReference
Four-wheel Drive (4WD) tractorReference
Built in CzechoslovakiaReference
Four-wheel driveReference
Articulated power steeringReference
Cab standard.Reference
Variants
ST180Nloader tractorReference
Engine
LIAZ 11.9L 6-cyl dieselReference
Fuel tank350.1 LReference
Engine134.2 kWReference
LIAZ M634Reference
dieselReference
6-cylinder 12-valveReference
liquid-cooled inlineReference
Displacement11.9 LReference
Bore/Stroke130 x 150 mmReference
Power134.2 kWReference
Compression16.2:1Reference
Rated RPM1800Reference
Firing order1-5-3-6-2-4Reference
StarterelectricReference
Starter volts24Reference
Oil capacity11.5 LReference
Coolant capacity45.0 LReference
Transmission
10-speed gearReference
TransmissionPraga 10P80Reference
TypegearReference
Gears10 forward and 2 reverseReference
Five gears, plus reverse, in two ranges.Reference
Dimensions
Wheelbase310 cmReference
Weight7484 kgReference
Front tire16.9/14-30Reference
Rear tire16.9/14-30Reference
Ag front16.9/14-30Reference
Ag rear16.9/14-30Reference
Length543 cmReference
Width245 cmReference
Height319 cmReference
Skoda-LIAZ ST180 attachments
front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
