Lawn Tractor · 2003Unverified
Snapper 280922B
Snapper 280922B — 22 Series · 9 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
9 hp
Weight
135 kg
Hover a source tag to verify
Overview
ManufacturerSnapperReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Engine
9HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)6.7 kWReference
Air cleanerdual elementReference
Starter typemanual recoilReference
Oil capacity1.4 LReference
Transmission
5-speed friction discReference
Typefriction discReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
Dimensions
Weight135 kgReference
Front tire4.10x4Reference
Rear tire16x6.50-8Reference
Lawn/turf front4.10x4Reference
Lawn/turf rear16x6.50-8Reference
Snapper 280922B attachments
28" mid-mount mower deckReference
bladeReference
Attachment overview
28" mid-mount mower deckReference
BladeReference
28" Mower deck
Typemid-mount SnapperReference
Type1-blade with manual liftReference
Cutting width71 cmReference
Cut height3 to 10 cmReference
Cut positions5Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
