Lawn Tractor · 2004Unverified
Snapper 2811523BV
Snapper 2811523BV — 23 Series · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Hover a source tag to verify
Overview
ManufacturerSnapper (a part of Briggs & Stratton)Reference
Riding lawn mowerReference
Built in McDonough, Georgia, USAReference
Original price$1,250 (2006 )Reference
Original price$1,400 (2009 )Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
11.5HP Briggs & Stratton 344cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & Stratton 21A902Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement21 ciReference
Bore/Stroke85 x 57 mmReference
Power (gross)8.6 kWReference
Starter typemanual recoilReference
Transmission
5-speed friction discReference
Typefriction discReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase116 cmReference
Front tire11x4.00-4Reference
Rear tire16x6.50-8Reference
Lawn/turf front11x4.00-4Reference
Lawn/turf rear16x6.50-8Reference
Length165 cmReference
Height99 cmReference
Snapper 2811523BV attachments
28" mid-mount mower deckReference
bladeReference
Attachment overview
28" mid-mount mower deckReference
BladeReference
28" Mower deck
Typemid-mount SnapperReference
Type1-blade with manual liftReference
Cutting width71 cmReference
Cut height3 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
