Lawn Tractor · 2003Unverified

Snapper 301022BE

Name: Snapper 301022BE
Brand: Snapper

Snapper 301022BE — 22 Series · 10 hp. Reference specifications; pending source verification.

The Snapper 301022BE is a compact lawn tractor with a 10 hp rated output. It features a 1-cylinder petrol air-cooled engine, connected to a 5-speed gearbox and two-wheel drive system. The 301022BE has a listed weight of 146 kg and is designed for use on areas up to 200 acres. It was manufactured in 2003.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

10 hp

Weight

146 kg

Catalogue coverage

Variants represented

Richest spec table

41 rows

Recorded power

10 hp

Transmissions

5-speed friction disc

Production years

2003-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSnapperReference

Riding lawn mowerReference

Two-wheel driveReference

Manual steeringReference

Drum brakesReference

Open operator station.Reference

Engine

10HP Briggs & Stratton 465cc 1-cyl gasolineReference

Fuel tank6.6 LReference

Briggs & StrattonReference

gasolineReference

1-cylinderReference

air-cooled vertical-shaftReference

Displacement28.4 ciReference

Bore/Stroke87 x 78 mmReference

Power (gross)7.5 kWReference

Air cleanerdual elementReference

StarterelectricReference

Starter volts12Reference

Oil capacity1.4 LReference

Transmission

5-speed friction discReference

Typefriction discReference

Gears5 forward and 1 reverseReference

PTO & Hydraulics

Mid PTOindependentReference

Dimensions

Weight146 kgReference

Front tire4.10x4Reference

Rear tire16x6.50-8Reference

Lawn/turf front4.10x4Reference

Lawn/turf rear16x6.50-8Reference

Snapper 301022BE attachments

30" mid-mount mower deckReference

bladeReference

Electrical

GroundnegativeReference

Charging amps3Reference

Battery CCA140Reference

Battery volts12Reference

Attachment overview

30" mid-mount mower deckReference

BladeReference

30" Mower deck

Typemid-mount SnapperReference

Type1-blade with manual liftReference

Cutting width76 cmReference

Cut height3 to 10 cmReference

Cut positions5Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
