The Snapper 301323BVE is a lawn tractor with a 13 hp rating, placing it in the middle of its class in terms of power. It features a 1-cylinder petrol air-cooled engine, coupled to a 5-speed gearbox and two-wheel drive. The 301323BVE has a listed weight of 160 kg and is suitable for areas of up to 200 acres. It was manufactured in 2003.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
160 kg
Catalogue coverage
Variants represented
2
Richest spec table
37 rows
Recorded power
13 hp
Transmissions
5-speed friction disc
Production years
2003-2003
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSnapperReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
13HP Briggs & Stratton 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Power (gross)9.7 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed friction discReference
Typefriction discReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
Dimensions
Wheelbase116 cmReference
Weight160 kgReference
Front tire11x4.00-4Reference
Rear tire16x6.50-8Reference
Lawn/turf front11x4.00-4Reference
Lawn/turf rear16x6.50-8Reference
Length162 cmReference
Height99 cmReference
Snapper 301323BVE attachments
30" mid-mount mower deckReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
30" mid-mount mower deckReference
BladeReference
30" Mower deck
Typemid-mount SnapperReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Overall width104 cmReference
Cut height3 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
