Lawn Tractor · 2007Unverified
Snapper 3317523BVE
Snapper 3317523BVE — 23 Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Hover a source tag to verify
Overview
ManufacturerSnapper (a part of Briggs & Stratton)Reference
Riding lawn mowerReference
Built in McDonough, Georgia, USAReference
Original price was $2,300 in 2009Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
17.5HP Briggs & Stratton 501cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & Stratton 31G777Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement30.6 ciReference
Bore/Stroke91 x 78 mmReference
Power (gross)13.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed friction discReference
Typefriction discReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase116 cmReference
Front tire11x4.00-4Reference
Rear tire16x6.50-8Reference
Lawn/turf front11x4.00-4Reference
Lawn/turf rear16x6.50-8Reference
Length165 cmReference
Height99 cmReference
Snapper 3317523BVE attachments
33" mid-mount mower deckReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
33" mid-mount mower deckReference
BladeReference
33" Mower deck
Typemid-mount SnapperReference
Type1-blade with manual liftReference
Cutting width83 cmReference
Cut height3 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
