Lawn Tractor · 2003Unverified
Snapper LT180H42
Snapper LT180H42 — Lawn tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
281 kg
Hover a source tag to verify
Overview
ManufacturerSnapperReference
Lawn tractorReference
Original price was $3,000 in 2005Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
18HP Briggs & Stratton 2-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Power (gross)13.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K-46Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Front PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase124 cmReference
Weight281 kgReference
Front tire15x5.50-6Reference
Rear tire20x10.00-8Reference
Lawn/turf front15x5.50-6Reference
Lawn/turf rear20x10.00-8Reference
Length167 cmReference
Width132 cmReference
Height101 cmReference
Snapper LT180H42 attachments
42" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
42" Mower deck
Typemid-mount SnapperReference
Type2-bladeReference
Cutting width106 cmReference
Overall width132 cmReference
Cut height3 to 9 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
