Lawn Tractor · 2006Unverified
Snapper LT2042
Snapper LT2042 — LT 200 Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
224 kg
Hover a source tag to verify
Overview
ManufacturerSnapper (a part of Briggs & Stratton)Reference
Lawn tractorReference
Original price was $2,350 in 2007Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
20HP Briggs & Stratton 2-cyl gasolineReference
Fuel tank13.2 LReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Power (gross)14.9 kWReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K-46Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase127 cmReference
Weight224 kgReference
Front tire15x6.00-6Reference
Rear tire20x8.00-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x8.00-8Reference
Length180 cmReference
Width93 cmReference
Height111 cmReference
Snapper LT2042 attachments
42" mid-mount mower deckReference
snowblowerReference
bladeReference
LT2042 Serial Number Location
Serial number decal on the left side of the tractor frame, just ahead of the footrest.Reference
Electrical
GroundnegativeReference
Battery CCA230Reference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
42" Mower deck
Typemid-mount SnapperReference
Type2-blade with manual liftReference
Cutting width106 cmReference
Cut height3 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
