Lawn Tractor · 1998Unverified
Snapper M280817B SR828
Snapper M280817B SR828 — 17 Series · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
130 kg
Hover a source tag to verify
Overview
ManufacturerSnapperReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power6.0 kWReference
Air cleanerdual dry elementReference
Starter typemanual recoilReference
Oil capacity1.1 LReference
Transmission
5-speed friction discReference
Typefriction discReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Weight130 kgReference
Front tire4.10x3.50Reference
Rear tire16x6.50-8Reference
Lawn/turf front4.10x3.50Reference
Lawn/turf rear16x6.50-8Reference
Snapper M280817B attachments
28" mid-mount mower deckReference
bladeReference
Attachment overview
28" mid-mount mower deckReference
BladeReference
28" Mower deck
Typemid-mount SnapperReference
Type1-bladeReference
Cutting width71 cmReference
Cut height3 to 10 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
