Lawn Tractor · 2011Unverified
Snapper NXT 19542
Snapper NXT 19542 — NXT Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Hover a source tag to verify
Overview
ManufacturerSnapper (a part of Briggs & Stratton)Reference
Lawn tractorReference
Original price was $2,299 in 2011Reference
Two-wheel driveReference
SteeringmanualReference
Engine
19.5HP Briggs & Stratton 499cc 1-cyl gasolineReference
Fuel tank13.2 LReference
Briggs & Stratton 31Q677Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement30.5 ciReference
Bore/Stroke91 x 78 mmReference
Power (gross)14.5 kWReference
Starterelectric push buttonReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K46Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Front PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase127 cmReference
Length180 cmReference
Width116 cmReference
Height114 cmReference
Front axleCast ironReference
Snapper NXT 19542 attachments
42" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery CCA230Reference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
42" Mower deck
Typemid-mount SnapperReference
Type2-blade with electric liftReference
Cutting width106 cmReference
Cut height3 to 10 cmReference
Cut positionsinfiniteReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
