Lawn Tractor · 2013Unverified
Snapper RE100
Snapper RE100 — Riding lawn mower · 5 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
5 hp
Hover a source tag to verify
Overview
ManufacturerSnapper (a part of Briggs & Stratton)Reference
Riding lawn mowerReference
Original price was $1,499 in 2014Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
5HP Briggs & Stratton 222cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton 14D937Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement13.6 ciReference
Bore/Stroke74 x 52 mmReference
Power3.7 kWReference
Torque13.6 NmReference
Torque RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed friction discReference
Typefriction discReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmechanicalReference
Dimensions
Front tire11x4.00-4Reference
Rear tire16x6.5-8Reference
Lawn/turf front11x4.00-4Reference
Lawn/turf rear16x6.5-8Reference
Length167 cmReference
Width81 cmReference
Height109 cmReference
Front axleSteelReference
Snapper RE100 attachments
28" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA35Reference
Battery volts12Reference
28" Mower deck
Typemid-mount SnapperReference
Type1-blade with manual liftReference
Cutting width71 cmReference
Cut height3 to 10 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
