Lawn Tractor · 2013Unverified
Snapper RE130
Snapper RE130 — Riding lawn mower · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Hover a source tag to verify
Overview
ManufacturerSnapper (a part of Briggs & Stratton)Reference
Riding lawn mowerReference
Original price was $1,799 in 2014Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
13.5HP Briggs & Stratton 344cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton PowerBuiltReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement21 ciReference
Bore/Stroke87 x 57 mmReference
Power (gross)10.1 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed friction discReference
Typefriction discReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmechanicalReference
Dimensions
Front tire11x4.00-4Reference
Rear tire16x6.5-8Reference
Lawn/turf front11x4.00-4Reference
Lawn/turf rear16x6.5-8Reference
Length167 cmReference
Width93 cmReference
Height109 cmReference
Front axleSteelReference
Snapper RE130 attachments
33" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA190Reference
Battery volts12Reference
33" Mower deck
Typemid-mount SnapperReference
Type1-blade with manual liftReference
Cutting width83 cmReference
Cut height3 to 10 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
