Lawn Tractor · 2014Unverified
Snapper ST2046
Snapper ST2046 — ST Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Hover a source tag to verify
Overview
ManufacturerSnapper (a part of Briggs & Stratton)Reference
Lawn tractorReference
Original price was $1,799 in 2014Reference
Two-wheel driveReference
SteeringmanualReference
Engine
20HP Briggs & Stratton 2-cyl gasolineReference
Fuel tank11.4 LReference
Briggs & Stratton IntekReference
gasolineReference
2-cylinderReference
air-cooled vertical shaft V-TwinReference
Power (gross)14.9 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro-Gear T2Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Front PTOindependentReference
ClutchmechanicalReference
Dimensions
Front tire15x6Reference
Rear tire20x8Reference
Lawn/turf front15x6Reference
Lawn/turf rear20x8Reference
Length175 cmReference
Width144 cmReference
Height106 cmReference
Front axleCast ironReference
Snapper ST2046 attachments
46" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA230Reference
Battery volts12Reference
46" Mower deck
Typemid-mount SnapperReference
Type2-blade with manual liftReference
Cutting width116 cmReference
Cut height2 to 10 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
