The Stanley 54ZS is a lawn tractor model with a rated engine power of 23 hp, positioning it within the more powerful machines of its class. It was produced from 2011 to 2015 and features a 2-cylinder petrol air-cooled engine, which drives the two-wheel drive system via a hydrostatic transmission. The listed weight of the Stanley 54ZS is 453 kg, and it is designed to handle areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
453 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
23 hp
Recorded weight
453 kg
Transmissions
hydrostatic
Production years
2011-2015
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorStanleyReference
ManufacturerGXi Outdoor PowerReference
Zero-turn mowerReference
Two-wheel driveReference
Power steeringReference
Two-post folding ROPS.Reference
Engine
23HP Kawasaki 726cc 2-cyl gasolineReference
Fuel tank28.4 LReference
Kawasaki FR691VReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaftReference
Displacement44.3 ciReference
Bore/Stroke76 x 76 mmReference
Power (gross)17.2 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionPeerless 2100Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Weight453 kgReference
Front tire15x6Reference
Rear tire22x10Reference
Lawn/turf front15x6Reference
Lawn/turf rear22x10Reference
Length210 cmReference
Height182 cmReference
Stanley 54ZS attachments
54" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
54" Mower deck
Typemid-mount StanleyReference
Type2-bladeReference
Cutting width137 cmReference
Cut height3 to 12 cmReference
Cut positions8Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
