Tractor · 1963Unverified
Steiger 2200
Steiger 2200 — Barn Series · 238 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
238 hp
Weight
10432 kg
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Red Lake Falls, Minnesota, USAReference
Four-wheel driveReference
Final drivesplanetaryReference
Articulated power steeringReference
Drum brakesReference
Open operator station. Cab available.Reference
Engine
Detroit Diesel 7.0L 6-cyl dieselReference
Engine177.5 kWReference
Detroit Diesel 6V71NReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.0 LReference
Bore/Stroke108 x 127 mmReference
Power177.5 kWReference
Air cleanerdryReference
Rated RPM2300Reference
Transmission
9-speedReference
TransmissionSpicerReference
Gears9 forward and 2 reverseReference
Clutch356mm discsReference
Capacities
Fuel507.2 LReference
PTO & Hydraulics
Hydraulic system204.4 LReference
Typeopen centerReference
Capacity204.4 LReference
Valves2Reference
Total flow151.4 lpmReference
Dimensions
Wheelbase335 cmReference
Weight10432 kgReference
Front tire23.1-26Reference
Rear tire23.1-26Reference
Ag front23.1-26Reference
Ag rear23.1-26Reference
Ag front23.1-30Reference
Ag rear23.1-30Reference
Width259 cmReference
Height269 cmReference
Front tread228 cmReference
Rear tread228 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
