Tractor · 1963Unverified
Steiger 3300
Steiger 3300 — Barn Series · 328 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
328 hp
Weight
14288 kg
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Red Lake Falls, Minnesota, USAReference
Four-wheel driveReference
Final drivesplanetaryReference
Articulated power steeringReference
Drum brakesReference
Open operator station. Cab available.Reference
Engine
Detroit Diesel 9.3L 8-cyl dieselReference
Engine244.6 kWReference
Detroit Diesel 8V71NReference
dieselReference
8-cylinderReference
liquid-cooledReference
Displacement9.3 LReference
Bore/Stroke108 x 127 mmReference
Power244.6 kWReference
Rated RPM2200Reference
Starter typeelectricReference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
Clutch394mm discsReference
Capacities
Fuel624.5 LReference
PTO & Hydraulics
Hydraulic system242.2 LReference
Typeopen centerReference
Capacity242.2 LReference
Pump flow189.2 lpmReference
Steering flow75.7 lpmReference
Dimensions
Wheelbase365 cmReference
Weight14288 kgReference
Front tire24.5-32Reference
Rear tire24.5-32Reference
Ag front24.5-32Reference
Ag rear24.5-32Reference
Width274 cmReference
Height279 cmReference
Front tread243 cmReference
Rear tread243 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
