Tractor · 1986Unverified
Steiger 9150
Steiger 9150 — Four-wheel Drive (4WD) tractor · 280 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
280 hp
Weight
10432 kg
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $95,000 in 1990Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Final drivesoutboard planetaryReference
Steeringhydrostatic powerReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 10.0L 6-cyl dieselReference
Engine (gross)208.8 kWReference
Cummins LTA-10Reference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement10.0 LReference
Bore/Stroke126 x 136 mmReference
Power (gross)208.8 kWReference
Rated RPM2100Reference
Torque1234.0 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity31.2 LReference
Coolant capacity56.8 LReference
Transmission
12-speed full power shiftReference
Typefull power shiftReference
Gears12 forward and 2 reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
PTO (claimed)193.1 kWReference
Hydraulic system68.1 LReference
Typeclosed centerReference
Capacity68.1 LReference
Pressure172.4 barReference
Valves3 to 4Reference
Total flow102.2 lpmReference
Rear TypeIIIReference
Rear lift5783 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Capacities
Fuel643.5 LReference
Dimensions
Wheelbase330 cmReference
Weight10432 kgReference
Front tire20.8-38Reference
Rear tire20.8-38Reference
Ag front20.8-38Reference
Ag rear20.8-38Reference
Length693 cmReference
Width237 cmReference
Height (hood)219 cmReference
Height (exhaust)363 cmReference
Shipping weight10432 kgReference
Max weight14515 kgReference
Ground clearance58 cmReference
Front axle101 by 3048 mmReference
Bar rear axle101 by 3048 mmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps100Reference
Batteries3Reference
Battery volts12Reference
Speeds
With 24.5x32 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
