Tractor · 1987Unverified

Steiger 9190

Name: Steiger 9190
Brand: Steiger

Steiger 9190 — Four-wheel Drive (4WD) tractor · 525 hp. Reference specifications; pending source verification.

The Steiger 9190 is a tractor with an approximate rating of 525 hp, placing it at the higher end of its class in terms of power output. It was manufactured in 1987. The tractor features a 6-cylinder turbocharged diesel liquid-cooled engine, which is paired with a hydrostatic transmission and four-wheel drive. It has an operating weight of 18470 kg and is suitable for operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

525 hp

Weight

18470 kg

Catalogue coverage

Variants represented

Richest spec table

50 rows

Recorded power

525 hp

Recorded weight

18470 kg

Transmissions

24-speed six-speed power shift

Production years

1987-1987

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteigerReference

Four-wheel Drive (4WD) tractorReference

Built in Fargo, North Dakota, USAReference

Original price was $191,000 in 1987Reference

Four-wheel driveReference

Steeringhydrostatic power articulatedReference

Disc brakesReference

Cab standard with air-conditioning and AM/FM cassette radio.Reference

Engine

Cummins 18.8L 6-cyl dieselReference

Engine391.5 kWReference

Drawbar (claimed)313.2 kWReference

Cummins KTA-1150Reference

turbocharged aftercooled dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement18.8 LReference

Bore/Stroke159 x 159 mmReference

Power391.5 kWReference

Rated RPM2100Reference

Torque2135.7 NmReference

Torque RPM1500Reference

Oil capacity71.9 LReference

Coolant capacity106.0 LReference

Transmission

24-speed six-speed power shiftReference

ManufacturerAllisonReference

Typesix-speed power shiftReference

Gears24 forward and 4 reverseReference

Six gears (1-6) plus reverse in four ranges.Reference

Capacities

Fuel1457.2 LReference

PTO & Hydraulics

Hydraulic system98.4 LReference

Typeopen centerReference

Capacity98.4 LReference

Pressure155.1 barReference

Valves4 or 5Reference

Total flow143.8 lpmReference

Dimensions

Wheelbase381 cmReference

Weight18470 kgReference

Front tire30.5-32Reference

Rear tire30.5-32Reference

Ag front30.5-32Reference

Ag rear30.5-32Reference

Length736 cmReference

Width302 cmReference

Width484 cmReference

Height (exhaust)408 cmReference

Ground clearance59 cmReference

9190 Serial Numbers

198717900844Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Speeds

With 30.5x32 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
