Tractor · 1976Unverified
Steiger Bearcat III ST-220
Steiger Bearcat III ST-220 — III Series · 220 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
220 hp
Weight
21400 to 24135 pounds
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $48,000 in 1977Reference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Safari Cab standard.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Fuel tank1010.6 LReference
Engine164.1 kWReference
Drawbar (claimed)130.5 kWReference
Cummins N-855-C220Reference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power164.1 kWReference
Compression15.8:1Reference
Rated RPM2100Reference
Torque873.3 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity41.6 LReference
Coolant capacity50.0 LReference
Transmission
20-speedReference
TransmissionSpicer SST 1010Reference
Gears20 forward and 4 reverseReference
Clutch394mm cerametallic discReference
Oil capacity56.8 LReference
PTO & Hydraulics
Typeopen centerReference
Pressure155.1 barReference
Valves3Reference
Pump flow103.0 lpmReference
SCV flow75.7 lpmReference
Rear TypeIIIReference
Rear lift4309 kgReference
Dimensions
Wheelbase325 cmReference
Weight21400 to 24135 poundsReference
Front tire23.1-30Reference
Rear tire23.1-30Reference
Ag front23.1-30Reference
Ag rear23.1-30Reference
Ag front24.5-32Reference
Ag front30.5-32Reference
Ag front18.4-34Reference
Ag front20.8-34Reference
Ag front23.1-34Reference
Ag front18.4-38Reference
Ag front20.8-38Reference
Ag rear24.5-32Reference
Ag rear30.5-32Reference
Ag rear18.4-34Reference
Ag rear20.8-34Reference
Ag rear23.1-34Reference
Ag rear18.4-38Reference
Ag rear20.8-38Reference
Length640 cmReference
Width241 cmReference
Shipping9707 kgReference
Shipping10947 kgReference
Bearcat III ST-220 Serial Numbers
1976103-00001Reference
1977103-00187Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Batteries2Reference
Battery volts12Reference
Battery AH208Reference
Battery Group8DReference
Capacities
Max capacity13608 kgReference
Steiger Bearcat III ST-220 Height
Hood235 cmReference
Cab337 cmReference
Exhaust390 cmReference
Speeds
With 23.1-30 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
