Search/Tractor/Steiger/Cougar III PT-270

Embed

Paste on your site — shows live UK/US specs and links back here. Free to use.

<iframe src="https://farmfleetspecs.com/embed/steiger-cougar-iii-pt-270" width="100%" height="430" loading="lazy" style="border:1px solid #e6e8e4;border-radius:14px;max-width:560px" title="Steiger Cougar III PT-270 specs — FarmFleetSpecs"></iframe>

Tractor · 1977Unverified

Steiger Cougar III PT-270

Name: Steiger Cougar III PT-270
Brand: Steiger

Steiger Cougar III PT-270 — III Series · 57 hp. Reference specifications; pending source verification.

The Steiger Cougar III PT-270 is a tractor with an approximate engine power output of 57 hp, placing it at the lighter end of its class. It was produced from 1977 to 1981. Key features of the tractor include a 6-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight is listed at 12,902 kg, with a maximum operating capacity of 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

57 hp

Weight

12902 kg

Catalogue coverage

Variants represented

Richest spec table

85 rows

Recorded power

57 hp

Recorded weight

12902 kg

Transmissions

20-speed constant mesh

Production years

1977-1981

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteigerReference

Four-wheel Drive (4WD) tractorReference

Built in Fargo, North Dakota, USAReference

Original price was $87,000 in 1981Reference

Four-wheel driveReference

Final drivesoutboard planetaryReference

Articulated power steeringReference

Hydraulic disc brakesReference

Safari Cab standard with air-conditioning.Reference

Engine

Caterpillar 10.5L 6-cyl dieselReference

Engine201.3 kWReference

Caterpillar 3306TAReference

turbocharged aftercooled dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement10.5 LReference

Bore/Stroke121 x 152 mmReference

Power201.3 kWReference

Compression17.5:1Reference

Rated RPM2200Reference

Idle RPM830-2480Reference

Starter volts12Reference

Oil capacity24.6 LReference

Coolant capacity53.0 LReference

Transmission

20-speed constant meshReference

Typeconstant meshReference

Gears20 forward and 4 reverseReference

Clutchhydraulic cerametallic dry discReference

Oil capacity15.1 LReference

Oil capacity35.0 LReference

Five-speed transmission with two ranges and a two-speed transfer case. Tractor must be stopped to shift ranges on transmission or transfer case.Reference

PTO & Hydraulics

PTO (claimed)42.5 kWReference

PTO (claimed)78.3 kWReference

Hydraulic system83.3 LReference

Typeopen centerReference

Capacity83.3 LReference

Pressure155.1 barReference

Valves4 or 5Reference

Pump flow75.7 lpmReference

Rear TypeIIIReference

Rear PTOindependentReference

Clutchhydrostatic-driveReference

Rear PTO Type540/1000Reference

Capacities

Fuel851.6 LReference

Dimensions

Wheelbase336 cmReference

Weight12902 kgReference

Front tire18.4-34Reference

Rear tire18.4-34Reference

Ag front18.4-34Reference

Ag rear18.4-34Reference

Ag front23.1-30Reference

Ag front24.5-32Reference

Ag front30.5-32Reference

Ag front20.8-34Reference

Ag front23.1-34Reference

Ag front18.4-38Reference

Ag front20.8-38Reference

Ag rear23.1-30Reference

Ag rear24.5-32Reference

Ag rear30.5-32Reference

Ag rear20.8-34Reference

Ag rear23.1-34Reference

Ag rear18.4-38Reference

Ag rear20.8-38Reference

Length672 cmReference

Width305 cmReference

Height (exhaust)395 cmReference

Shipping weight12902 kgReference

Max weight14515 kgReference

Front axleRaba 598Reference

Raba 598 rear axleReference

Cougar III PT-270 Serial Numbers

1977143-00001Reference

1978143-00082Reference

1979143-00154Reference

1980143-00211Reference

1981143-00236Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Charging volts12Reference

Batteries4Reference

Battery CCA475Reference

Battery volts12Reference

Speeds

With 18.4x34 tires and S-34 axles.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
