Tractor · 1983Unverified
Steiger Cougar IV KM-280
Steiger Cougar IV KM-280 — IV Series · 280 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
280 hp
Weight
11344 kg
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Steiger Safari Cab standard with air-conditioning.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Fuel tank1010.6 LReference
Engine208.8 kWReference
Drawbar (claimed)190.2 kWReference
Cummins NT-855-AReference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power208.8 kWReference
Rated RPM2100Reference
Operating RPM1700-2100Reference
Torque1234.0 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Oil capacity33.1 LReference
Coolant capacity57.9 LReference
Transmission
20-speed gearReference
TypegearReference
Gears20 forward and 4 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure155.1 barReference
Valves3 to 5Reference
Pump flow108.3 lpmReference
Rear TypeIIIReference
Dimensions
Wheelbase327 cmReference
Weight11344 kgReference
Front tire18.4x38Reference
Rear tire18.4x38Reference
Ag front18.4x38Reference
Ag rear18.4x38Reference
Ag front20.8x34Reference
Ag front20.8x38Reference
Ag front23.1x34Reference
Ag front24.5x32Reference
Ag front30.5x32Reference
Ag rear20.8x34Reference
Ag rear20.8x38Reference
Ag rear23.1x34Reference
Ag rear24.5x32Reference
Ag rear30.5x32Reference
Length644 cmReference
Width243 cmReference
Width366 cmReference
Shipping weight11344 kgReference
Max weight15422 kgReference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Batteries3Reference
Battery volts12Reference
Steiger Cougar IV KM-280 Height
240 cmReference
Cab342 cmReference
Exhaust395 cmReference
Speeds
With 18.4x38 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
